4BTA3.9 -c80 |
4BTA3.9 -c100 |
4BTA3.9 -c125 |
4BTA3.9 -c130 |
|
|
Cyl No. and Arrangement |
4-Cyl in-line |
|||
|
Bore/Stroke(mm) |
102/120 |
|||
|
Air-intake way |
Turbo charged cooling |
|||
|
Combustion system |
Direct injection |
|||
|
Cooling way |
Water-cooled |
|||
|
Displacement(L) |
3.9 |
|||
|
Max.Torque(N.m) |
300 |
400 |
450 |
500 |
|
Power(kw) |
80 |
100 |
125 |
130 |
|
Power(hp) |
107 |
134 |
168 |
174 |
|
Speed(rpm) |
2500 |
|||
|
Net Weight(kg) |
340 |
|||
|
Weight(kg) |
370 |
|||
|
Dimension(L*W*H/cm) |
80*60*85 |
|||
|
Application: |
construction machinery / generator set / mining equiment / water pump / truck |
|||
|
Certification |
ISO9001:2000 |
|||
|
Warranty |
12 Months / 1000 Hours |
|||
|
Quality Control |
The engines have been rigorously tested |
|||
|
Payment |
T/T, Western Union, Alibaba online payment. |
|||
|
Service |
Guidance on product issues through online and video support |
|||
|
The price varies based on configu-ration, serial number, and part quality. For an accurate quote, contact a supplier with your specific engine serial number ornameplate. |
||||
